Which DIGIWAY door operator is right for your project? If you're not sure whether to go for a Plus or an SR, consult this guide for support.
Scorri per saperne di più
DIGIWAY is a universal automation solution for both interior and exterior doors, adaptable for both single and double doors. With a built-in receiver and free programming app, all parameters can be quickly and easily configured, making installations simple and successful.
There are two distinct models of DIGIWAY door operators:
DIGIWAY PLUS is electro-mechanically driven and specifically designed to improve accessibility into and around buildings for people with reduced mobility, making it ideal for residential or care home projects.
DIGIWAY SR (Spring Return) is assisted by a chain-driven mechanism, making it particularly suitable for higher traffic sites. DIGIWAY SR is also fire rated to the EN1634-1 standard for up to 60 minutes.
It’s important that you choose the right DIGIWAY model for your installation. Check the table below to find out how to identify the correct model.
DIGIWAY PLUS | DIGIWAY SR | |
Max Door Weight* | 120kg | 200kg |
Max Door Width* | 1.2m | 1.5m |
Power | 50W | 100W |
Dimensions (mm) | 511 x 50 x 110 | 685 x 90 x 110 |
Lock Power | 12Vdc – 1A | 12Vdc – 1A / 24Vdc – 0.5A |
Fire Input | Power 24-48Vdc | NC contact |
Semi-Automatic Mode | – | Yes |
Battery Failover | Yes | – |
Spring Return | – | Yes |
Software-Assisted Spring Pre-Load | – | Yes |
Fire Rated | – | Yes |
*At max door weight, width dimension reduces. See Suitability of Installation Questionnaire for details.
